Glazing Structures

Curving The Impossible

Architects aspire to create entirely transparent facades and eliminating supporting structures in aluminum or steel.

ΗΕΧΑΝΟΜ offers the possibility to do it with frameless glass facades with an all-glass design.

This type of construction completely eliminates steel or aluminum studs. Instead, structural glass facades use transparent reinforcing elements – self-supporting vertical glass poles that extend from floor to ceiling. They have extremely thin cross-sections and are very rigid.

Minimalist, maximum transparency, large glass formats, extraordinary attention to detail: these are the attributes of the building envelopes that HEXANOM creates for world-renowned architects.

HEXANOM opens up completely new possibilities for glass structures. We develop on a case-by-case basis to combine project aesthetics and performance with smart design and precision engineering.

To create lasting values and ensure our customers’ trust, we guarantee the excellence of products and services in light of our principles and standards.

We Are Always Looking For Our Next Organic Challenge!

Quality Standard: GB/T 15763.2 – ASTM C 1048 – ASTM C 1464 – EN 1863 – EN 12150  /  Minimum radius 300mm

Yearly capacity: 63800 mtr2

Thickness: 5,6,8,10,12,15,19,22,25 mm

Line 1: W2800 x H6500

Line 2: W2600 x H4000

Line 3: W2400 x H2800

Line 4: W3300 x H7000

Line 5: W2400 x H3500

Quality Standard: GB/T 15763.2 – ASTM C 1048 –  EN 1863 – EN 12150

Thickness: 5,6,8,10,12,15,19,22,25 mm

Line 1: W2800 x H2750 / min. radius: 1100mm / Yearly capacity: 180000 mtr2 / min. size: W600x H600

Line 2: W2600 x H5500 / min. radius: 1400mm / Yearly capacity: 320000 mtr2 / min. size: W600x H600

Line 3: W3300 x H3300 / min. radius: 1400mm / Yearly capacity: 186000 mtr2 / min. size: W600x H600

Line 4: W3000 x H6000 / min. radius: 1400 – 2000mm / Yearly capacity: 250000 mtr2 / min. size: W600x H600



Quality Standard: GB/T 15763.2 – ASTM C 1172 –  EN 1863 – EN 12150

Thickness: Multiple /  Min. radius: Multiple

Line 1: W2400 x H3500 / Yearly capacity: 117600 mtr2 / min. size: W600x H600

Line 2: W2400 x H4200 / Yearly capacity: 127000 mtr2 / min. size: W600x H600





Quality Standard: GB/T 15763.3 – ASTM C 1172 –  EN 14449 – AN/NZS 2208

Thickness: Multiple

Line 1#Flat: W2600 x H6000 / Yearly capacity: 336000 mtr2 / min. size: W100x H100

Line 2#Curved: W2600 x H6000 /  Min. radius: 1100mm / Yearly capacity: 185000 mtr2 / min. size: W100x H100

Line 3#Flat: W3300 x H7000 / Yearly capacity: 504000 mtr2 / min. size: W100x H100

Line 4#Flat: W2400 x H15000 / Yearly capacity: 420000 mtr2 / min. size: W100x H100

Line 5#Curved: W3300 x H3300 /  Min. radius: 1400mm / Yearly capacity: 268000 mtr2 / min. size: W100x H100

Line 6#Curved: W3000 x H6000 /  Min. radius: 1400 – 2000mm /  Yearly capacity: 336000 mtr2 / min. size: W100x H100

Quality Standard: GB/T 11944 – ASTM E 2190 –  EN 1279

Thickness: Multiple

Line 1#Flat: W2440 x H3500 / Yearly capacity: 504000 mtr2 / min. size: W100x H100

Line 2#Flat: W2800 x H6250 / Yearly capacity: 520000 mtr2 / min. size: W100x H100

Line 3#Flat: W3300 x H8000 / Yearly capacity: 670000 mtr2 / min. size: W100x H100

Line 4#Flat: W2400 x H16000 / Yearly capacity: 732000 mtr2 / min. size: W100x H100

Line 5#Curved: W2800 x H2750 /  Min. radius: 1100mm / Yearly capacity: 295000 mtr2 / min. size: W300x H300

Line 6#Curved: W2500 x H5300 /  Min. radius: 1400mm / Yearly capacity: 520000 mtr2 / min. size: W300x H300

Line 7#Curved: W3300 x H3300 /  Min. radius: 1400mm / Yearly capacity: 336000 mtr2 / min. size: W300x H300

Line 8#Curved: W3000 x H6000 /  Min. radius: 1400 – 2000 mm / Yearly capacity: 454000 mtr2 / min. size: W300x H300


Quality Standard:  ASTM C1048 – GB/T 15763.2 – ASTM C1279 – ASTM C1048 – BS 6206 – EN 12150.1 – AS/NZS 2208

Thickness: 4,5,6,8,10,12,15,19,22,25 mm

Line 1: W2800 x H6240 / Min. Radius: 1100 mm /  Yearly capacity: 672000 mtr2 / min. size: W300x H300

Line 2: W2650 x H5000 / Min. Radius: 1400 mm /  Yearly capacity: 672000 mtr2 / min. size: W300x H300

Line 3: W3300 x H7000 / Min. Radius: 1400 mm /  Yearly capacity: 559000 mtr2 / min. size: W300x H300

Line 4: W2400 x H15500 / Min. Radius: 1400 – 2000 mm /  Yearly capacity: 870000 mtr2 / min. size: W600x H600



Quality Standard:  ASTM C1048

Thickness: 4,5,6,8,10,12,15,19,22,25 mm

Line 1: W2800 x H6240 / Min. Radius: 1100 mm /  Yearly capacity: 672000 mtr2 / min. size: W300x H300

Line 2: W2650 x H5000 / Min. Radius: 1400 mm /  Yearly capacity: 672000 mtr2 / min. size: W300x H300

Line 3: W3300 x H7000 / Min. Radius: 1400 mm /  Yearly capacity: 559000 mtr2 / min. size: W300x H300

Line 4: W2400 x H15500 / Min. Radius: 1400 – 2000 mm /  Yearly capacity: 870000 mtr2 / min. size: W600x H600

Quality Standard:  ASTM C1048

Thickness: 4,5,6,8,10,12,15,19,22,25 mm

Line 1: W2400 x H4500 / Yearly capacity: 272000 mtr2 / min. size: W100x H100

Line 2: W1800 x H5800 / Yearly capacity: 255000 mtr2 / min. size: W100x H100

Line 2: W3300 x H6000 / Min. Radius: 1400 – 2000 mm /  Yearly capacity: 534000 mtr2 / min. size: W100x H100

Quality Standard: BS/EN 14179
